RUBADUE WIRE 产品规格（Specifications）
如您对RUBADUE WIRE产品编号原则清楚了解，您可以按照料号规则点击下面PDF档案。如果您对RUBADUE Wire想做进一步了解，可以联系我们或者点击这里按照分类查找！谢谢您对本公司代理产品的支持！
| Insulated Wires Specification |
Size Range | |
| DXXA01TXX-1 | 30 AWG to 40 AWG | open |
| DXXAXXFXX-2 | 20 AWG to 40 AWG | open |
| DXXAXXFXX-3 | 16 AWG to 40 AWG | open |
| DXXAXXPXX-1.5 | 28 AWG to 40 AWG | open |
| DXXAXXPXX-2 | 16 AWG to 40 AWG | open |
| DXXAXXTXX-1.5 | 18 AWG to 40 AWG | open |
| DXXAXXTXX-2 | 16 AWG to 40 AWG | open |
| SXXA01FX-2 | 20 AWG to 40 AWG | open |
| SXXA01FX-3 | 20 AWG to 40 AWG | open |
| SXXA01PX-1.5 | 28 AWG to 40 AWG | open |
| SXXA01PX-2 | 20 AWG to 40 AWG | open |
| SXXA01PX-3 | 16 AWG to 40 AWG | open |
| SXXAXXTX-1.5 | 28 AWG to 40 AWG | open |
| SXXAXXTX-2 | 20 AWG to 40 AWG | open |
| SXXAXXTX-3 | 16 AWG to 40 AWG | open |
| TCA 1 | 26 AWG to 40 AWG | open |
| TCA 2 | 18 AWG to 40 AWG | open |
| TCA 3 | 18 AWG to 40 AWG | open |
| TXXA01TXXX-1 | 30 AWG to 40 AWG | open |
| TXXAXXFXXX-2 | 16 AWG to 40 AWG | open |
| TXXAXXFXXX-3 | 10 AWG to 36 AWG | open |
| TXXAXXFXXX-5 | 10 AWG to 30 AWG | open |
| TXXAXXPXXX-1.5 | 18 AWG to 40 AWG | open |
| TXXAXXPXXX-2 | 16 AWG to 40 AWG | open |
| TXXAXXPXXX-3 | 16 AWG to 32 AWG | open |
| TXXAXXTXXX-1.5 | 18 AWG to 40 AWG | open |
| TXXAXXTXXX-2 | 14 AWG to 40 AWG | open |
| TXXAXXTXXX-3 | 14 AWG to 40 AWG | open |
RUBADUE WIRE 编号原则说明：
| T | Triple layer (D=Double， S=Single) | ||
| 30 | AWG size (Gauge Size) | ||
| A | Conductor Material | ||
| A- TPC (Tin Plated Copper) | B- SPC (Silver Plated Copper) | C- BC (Bare Copper) | |
| CW- Copper Weld | D- SPA 135 | E- Enamel (MW80) Single build | |
| EH- Enamel (Heavy Build) | G- Alloy 60 | H- Heavy Solidex Enamel (MW 77) | |
| HM- Enamel (HML) | J- 99.99% Pure Copper (Audio) | L- Litz Wire | |
| M- Enamel (MW 35) | N- NPC (Nickel Plated Copper) | NA- Nickel Alloy (further spec required) | |
| O- OFHC BC | Q- QPN (Quad Poly Nylon) | R- Alloy 180 | |
| S- Stainless Steel | U- Cupron | X- CFM (Customer Furnished Materials) | |
| Y- Alloy 90 | |||
| 01 | Numbers of Strands in Conductor | ||
| T | Insulation Type | ||
| XXX | Color Code | ||
| 0-Black | 1-Brown | 2- Red | |
| 3- Orange | 4- Yellow | 5- Green | |
| 6- Blue | 7- Violet | 8- Grey | |
| 9- White | |||
| -2 | Wall Thickness per Layer(-2=2mil=0.051mm) | ||
