Basic (1 layer) Insulated DuPont ECA 3000 300°c wire
Product Information
Wire Category:
Basic (1 layer)
Insulation:
DuPont™ Ecctreme® ECA 3000
Size Range:
8 AWG - 30 AWG
Compliances:
- RoHS Compliant
- UL OBJT2 File No. E206198
Voltage Rating:
Potential 600 V Rating*
Conductor:
27% Nickel plated copper, Solid or Stranded (ASTM B355)
Insulation Information
Insulation Type:
Perfluoropolymer
Thermal:
Continuous Operating Temperature, 300°c
UL Flammability Rating:
V-0
Dielectric Constant:
2.09
Tensile Strength (psi):
2280
Elongation(%):
194%
Abrasion Resistance:
Good
Bondability:
Poor
UV Resistance:
Excellent
Chemical Resistance:
Excellent
Water Resistance:
Excellent
Underground Resistance:
Excellent
Long Term Stability:
Excellent
ECA 3000 is a Perfluoropolymer compound with superior heat resistance, exceptional dielectric properties, and chemical resistance. Commonly used in applications that requiring a higher operating temperature. * UL Approvals Pending
Insulated Wire Information:
| Part Number | AWG | Inches | MM | Inches | MM |
|---|---|---|---|---|---|
| S8NC133ECC-10 | 8 (133/29) | 0.1674 | 4.2520 | 0.1874 | 4.7599 |
| S12NC19ECC-7 | 12 (19/25) | 0.0855 | 2.1717 | 0.0995 | 2.5273 |
| S14NC19ECC-7 | 14 (19/27) | 0.0700 | 1.7780 | 0.0840 | 2.1336 |
| S16NC19ECC-5 | 16 (19/29) | 0.0546 | 1.3868 | 0.0646 | 1.6408 |
| S25NC01ECC-5 | 25 | 0.0182 | 0.4623 | 0.0282 | 0.7163 |
| S26NC01ECC-5 | 26 | 0.0160 | 0.4064 | 0.0260 | 0.6604 |
| S30NC01ECC-4 | 30 | 0.0102 | 0.2591 | 0.0202 | 0.5131 |
